LED wall light 10W 765Lm 4200ºK Spring-1 40,000H [HO-WL-SPRING-1-10W-W]

LED wall light 10W 765Lm 4200ºK Spring-1 40,000H [HO-WL-SPRING-1-10W-W]

See questions and answers

Brand:GreenIce Deco + Luce Viva
SKU:HO-WL-SPRING-1-10W-W

Eprel file

	Reference	Stock	Price	Discount	Amount
	4200K: Daylight SKU: HO-WL-SPRING-1-10W-W Delivery in 48 h ... if you ask before	There are few	Usual price £16.00 Usual price Offer price £16.00 Unit price by
	2700K: Warm White SKU: HO-WL-SPRING-1-10W-WW Delivery in 48 h ... if you ask before	Stock available	Usual price £5.00 Usual price Offer price £5.00 Unit price by

For additional amounts the delivery period is 60 days As of the order date

Documents

Warranty

Warranty 3 years

120 º Opening

Accessories

Switch Panasonic Karre 10A 250V/Metal Frame With Claws/Key White

Supplier:
PANASONIC

Switch Panasonic Karre 10A 250V/Metal Frame With Claws/Key White

Usual price £4.00

Usual price Offer price £4.00
Unit price by

Technical file

Product code

HO-WL-SPRING-1-10W-W

Light temperature

Natural White

Power (W)

10.0

Luminosity (LM)

765

Luminous efficacy (LM/W)

76

Type of LEDs

SMD2835

Number of LEDs

50

LED efficacy

83

Opening Angle (º)

120

CRI

80

Power factor (PF)

0.8

Construction

Aluminum/ PC

Facility

IP20

Strain

85-265VAC

Driver output

DC72-96V

Long

250.0

Measures (mm)

250x150x100

Broad

100.0

High

150.0

Isolation class

II

Estimated life (H)

40000

Equivalence (W)

90

Work frequency (Hz)

50/ 60

Start time (s)

0.1

Energy class

G

Certificates

CE/ROHS/ISO9001

Bush

Terminal Block

Temperature range (ºC)

-20 +40

Lighting cycles

100000

Diffuser

Opal

Kelvin º

4200

Energy consumption (kWh/1000h)

10.0

Weight (gr)

300

Flicker

0.77

Half -year useful life (at 3 h/day)

36.52

Half -Year Useful Life (5 h/day)

21.91

Half -year useful life (at 8 h/day)

13.69

Single CCT

4200

INDEX R9

1

Minimum cri range

95

Maximum cri range

19

Chromaticity x

0.323

Chromaticity and

0.352

Style

Modern

Lamp type

Apply

Applicable standards

EN 60598-1:2008; EN 60598-2-2:2012: EN 62493:2010

Characteristics

Product code

HO-WL-SPRING-1-10W-W

Light temperature

Natural White

Power (W)

10.0

Luminosity (LM)

765

Luminous efficacy (LM/W)

76

Type of LEDs

SMD2835

Number of LEDs

50

LED efficacy

83

Opening Angle (º)

120

CRI

80

Power factor (PF)

0.8

Construction

Aluminum/ PC

Facility

IP20

Strain

85-265VAC

Driver output

DC72-96V

Long

250.0

Measures (mm)

250x150x100

Broad

100.0

High

150.0

Isolation class

II

Estimated life (H)

40000

Equivalence (W)

90

Work frequency (Hz)

50/ 60

Start time (s)

0.1

Energy class

G

Certificates

CE/ROHS/ISO9001

Bush

Terminal Block

Temperature range (ºC)

-20 +40

Lighting cycles

100000

Diffuser

Opal

Kelvin º

4200

Energy consumption (kWh/1000h)

10.0

Weight (gr)

300

Flicker

0.77

Half -year useful life (at 3 h/day)

36.52

Half -Year Useful Life (5 h/day)

21.91

Half -year useful life (at 8 h/day)

13.69

Single CCT

4200

INDEX R9

1

Minimum cri range

95

Maximum cri range

19

Chromaticity x

0.323

Chromaticity and

0.352

Style

Modern

Lamp type

Apply

Applicable standards

EN 60598-1:2008; EN 60598-2-2:2012: EN 62493:2010

Description

The SPRING LED Wall Light has a modern white finish to easily adapt to the desired design. It offers solutions for residential and commercial use. It can be installed directly to the sockets supplied by the electrical network (85-265VAC) with a service frequency of 50/60Hz.

The Wall Lamp has a high efficiency (90 Lm/W ) consuming 10W through LEDs Type SMD2835, achieving a total luminous flux of 900Lm, emitting light uniformly with a color rendering index of 80. Its consumption represents a value of 10kWh/1000h, reducing the amount of energy billed and emissions of polluting gases into the atmosphere. This Wall Lamp has an IP25 protection degree (valid for dust and humidity indoors). Additionally, it is robust enough for the required mechanical demands. It has a white finish.

Its pure geometric shapes are inspired by Nordic design. Its discreet design makes it integrate smoothly with the environment. It projects homogeneous light on the wall to create a sober and welcoming atmosphere.

Thus, it is ideal for hotel corridors, bars and restaurants. It is also an ideal solution for rooms where you seek to create comfort and relaxation, such as waiting rooms in hospitals, clinics, or other businesses that serve the public.

This Wall Lamp is available in natural white ( 4200°K) and warm white (3000°K). The indicated color temperature may suffer fluctuations corresponding to a tolerance of 7%.
