LED Wall Light IP65 Cross 4W 300Lm 40,000H Madelyn

LED Wall Light IP65 Cross 4W 300Lm 40,000H Madelyn

See questions and answers

  • Brand:GreenIce
  • SKU:MK-CSL-4W-CW
Eprel file
Reference Stock Price Discount Amount
6000K: Cool White
SKU: MK-CSL-4W-CW
Delivery in 48 h ... if you ask before
There are few
£4.00
£4.00
For additional amounts the delivery period is 60 days As of the order date

Warranty

  • Warranty 3 years
  • 120 º Opening

Technical file

Product code
MK-CSL-4W-CW
Light temperature
Cold
Power (W)
4.0
Luminosity (LM)
300
Luminous efficacy (LM/W)
75
Type of LEDs
Epistar
Number of LEDs
1
LED efficacy
82
Opening Angle (º)
120
CRI
85
Power factor (PF)
0.9
Construction
Aluminum/ PC
Facility
IP65
Strain
85-265VAC
Driver output
DC18-35V
Measures (mm)
Ø50x55
High
55.0
Isolation class
I
Estimated life (H)
40000
Dimable
No
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
G
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20 +65
Lighting cycles
100000
Diffuser
Opal
Kelvin º
6000
Energy consumption (kWh/1000h)
4.0
Weight (gr)
220
Flicker
0.95
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Single/range CCT
Only
Single CCT
6000
INDEX R9
24
Minimum cri range
95
Maximum cri range
1
Chromaticity x
0.323
Chromaticity and
0.352
IK Protection Index
IK07
Diameter
50
Número unidades caja exterior
50.0

Characteristics

Product code
MK-CSL-4W-CW
Light temperature
Cold
Power (W)
4.0
Luminosity (LM)
300
Luminous efficacy (LM/W)
75
Type of LEDs
Epistar
Number of LEDs
1
LED efficacy
82
Opening Angle (º)
120
CRI
85
Power factor (PF)
0.9
Construction
Aluminum/ PC
Facility
IP65
Strain
85-265VAC
Driver output
DC18-35V
Measures (mm)
Ø50x55
High
55.0
Isolation class
I
Estimated life (H)
40000
Dimable
No
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
G
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20 +65
Lighting cycles
100000
Diffuser
Opal
Kelvin º
6000
Energy consumption (kWh/1000h)
4.0
Weight (gr)
220
Flicker
0.95
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Single/range CCT
Only
Single CCT
6000
INDEX R9
24
Minimum cri range
95
Maximum cri range
1
Chromaticity x
0.323
Chromaticity and
0.352
IK Protection Index
IK07
Diameter
50
Número unidades caja exterior
50.0

Description

The 'CROSS' IP65 Outdoor LED Wall Light offers great strength and quality, as well as important directional lighting for your outdoor space.

Natural and safe light , without flickering, reflections, UV or infrared radiation. Ideal for decorative outdoor lighting in gardens, paths, entrances and patios. In addition, it serves as a decoration for outdoor objects and furniture, low-profile lighting and small spaces.It has an opening angle of 4x5º with direct connection to 85-265VAC.

Documents

Installation_manual
Technical_drawings
