Linear Surface LED Luminaire 50W 120Lm/W 6000Lm 6000ºK 150Cm 40,000H [HO-LLS-506000150-CW]

Linear Surface LED Luminaire 50W 120Lm/W 6000Lm 6000ºK 150Cm 40,000H [HO-LLS-506000150-CW]

See questions and answers

  • Brand:GreenIce + Osram Led
  • SKU:HO-LLS-506000150-CW
Eprel file
Reference Stock Price Discount Amount
6000K: Cool White
SKU: HO-LLS-506000150-CW
Delivery in 48 h ... if you ask before
Stock available
£8.00
£8.00
4200K: Daylight
SKU: HO-LLS-506000150-W
Delivery in 48 h ... if you ask before
Stock available
£8.00
£8.00
2700K: Warm White
SKU: HO-LLS-506000150-WW
Delivery in 48 h ... if you ask before
Stock available
£8.00
£8.00
For additional amounts the delivery period is 60 days As of the order date

Warranty

  • Warranty 3 years
  • Eye Care Eye Care
  • 120 º Opening

Accessories

Technical file

Product code
HO-LLS-506000150-CW
Light temperature
Cold White
Power (W)
50.0
Luminosity (LM)
6000
Luminous efficacy (LM/W)
120
Type of LEDs
Osram LED
Number of LEDs
250
LED efficacy
132
Opening Angle (º)
120
CRI
80
Power factor (PF)
0.98
Construction
Aluminum/PC
Facility
IP20
Strain
160-265VAC
Long
1500.0
Measures (mm)
1500
Isolation class
II
Estimated life (H)
40000
Dimable
No
Work frequency (Hz)
50/60
Start time (s)
0.1
Energy class
E
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20+40
Lighting cycles
100000
Diffuser
Opal
Kelvin º
6000
Energy consumption (kWh/1000h)
50.0
Weight (gr)
420
Flicker
0.78
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
14
Minimum cri range
5
Maximum cri range
93
Chromaticity x
0.307
Chromaticity and
0.329
IK Protection Index
IK07
Número unidades caja exterior
20.0
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001

Characteristics

Product code
HO-LLS-506000150-CW
Light temperature
Cold White
Power (W)
50.0
Luminosity (LM)
6000
Luminous efficacy (LM/W)
120
Type of LEDs
Osram LED
Number of LEDs
250
LED efficacy
132
Opening Angle (º)
120
CRI
80
Power factor (PF)
0.98
Construction
Aluminum/PC
Facility
IP20
Strain
160-265VAC
Long
1500.0
Measures (mm)
1500
Isolation class
II
Estimated life (H)
40000
Dimable
No
Work frequency (Hz)
50/60
Start time (s)
0.1
Energy class
E
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20+40
Lighting cycles
100000
Diffuser
Opal
Kelvin º
6000
Energy consumption (kWh/1000h)
50.0
Weight (gr)
420
Flicker
0.78
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
14
Minimum cri range
5
Maximum cri range
93
Chromaticity x
0.307
Chromaticity and
0.329
IK Protection Index
IK07
Número unidades caja exterior
20.0
Applicable standards
EN 55015:2009;EN 61547:2009:EN 61000-3-2:2006;EN 61000-3-3:2008;EN 60598-2-2:2012;EN 60598-1:2009;EN 1122B:2001

Description

The Linear Surface LED Luminaire has a wide opening angle to offer general lighting with high efficiency. Ease of installation on any type of ceiling, whether plaster, concrete or any other surface.

With an opal diffuser that provides general lighting without reflections. Ideal for replacing traditional halogens, reaching savings of up to 90%, and conventional low-consumption downlights, reaching savings of up to 60%, achieving high energy efficiency. Easy installation, long life of the LED luminaire, more than 40,000 hours and maintenance free.

Clean and architectural design where the latest LED technology is adapted to the simplicity of the linear lamp that offers a diffuse and soft light. It provides general and widely diffused lighting.

The perfect solution to create an elegant environment, in new construction or renovation, to replace current spotlights, for the home, offices, receptions, museums, bars, etc.
