LED Pool Spotlight 25W Par 56 RGBW Control 40,000H [KD-PAR56-25W-RGB]

LED Pool Spotlight 25W Par 56 RGBW Control 40,000H [KD-PAR56-25W-RGB]

See questions and answers

  • Brand:GreenIce + Epistar Led
  • SKU:HO-PAR56-25W-RGBW
Reference Stock Price Discount Amount
RGB-Daylight
SKU: HO-PAR56-25W-RGBW
Ask for it and get free in 60 days
Exhausted
35,20€
35,20€
For additional amounts the delivery period is 60 days As of the order date

Warranty

  • Warranty 3 years
  • 120 º Opening

Accessories

Technical file

Product code
HO-PAR56-25W-RGB
Light temperature
RGB
Power (W)
25.0
Type of LEDs
Epistar Led
Number of LEDs
24
Opening Angle (º)
120
Construction
Stainless steel
Facility
IP68
Strain
12VAC
Driver output
DC12V 2900MA
Measures (mm)
120xØ177
High
97.0
Isolation class
III
Estimated life (H)
40000
Dimable
No
Work frequency (Hz)
50/ 60
Start time (s)
0.2
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-40 +60
Lighting cycles
80000
Diffuser
Opal
Energy consumption (kWh/1000h)
25.0
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Single/range CCT
Range
Additional information
Transformer required in the "accessories" tab
RM Pro remote control code
F-KD-PAR56-25W
IK Protection Index
IK10
Diameter
Ø177
Número unidades caja exterior
12.0
Applicable standards
EN 55015:2013; EN 61547:2009; EN 61000:2009

Characteristics

Product code
HO-PAR56-25W-RGB
Light temperature
RGB
Power (W)
25.0
Type of LEDs
Epistar Led
Number of LEDs
24
Opening Angle (º)
120
Construction
Stainless steel
Facility
IP68
Strain
12VAC
Driver output
DC12V 2900MA
Measures (mm)
120xØ177
High
97.0
Isolation class
III
Estimated life (H)
40000
Dimable
No
Work frequency (Hz)
50/ 60
Start time (s)
0.2
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-40 +60
Lighting cycles
80000
Diffuser
Opal
Energy consumption (kWh/1000h)
25.0
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Single/range CCT
Range
Additional information
Transformer required in the "accessories" tab
RM Pro remote control code
F-KD-PAR56-25W
IK Protection Index
IK10
Diameter
Ø177
Número unidades caja exterior
12.0
Applicable standards
EN 55015:2013; EN 61547:2009; EN 61000:2009

Description

The PAR 56 LED Pool Spotlight with a diameter of 177mm and a thickness of 97mm, is designed to be installed to replace the halogen PAR56 lamps used in the past. It is perfect as decorative lighting inside the pool and can be installed at 12VAC.

It has a high efficiency consuming 25W through SMD5050 LEDs, with an opening angle of 120°, obtaining a color rendering index of 80 It replaces the traditional 300W PAR56 models, its consumption represents a value of 25kWh/1000h, reducing the amount of energy billed and the emissions of polluting gases into the atmosphere. A remote control is included which, by means of a controller located inside the spotlight, manages the desired color and effects.

This spotlight is completely waterproof and supports complete and continuous immersion. Its installation is carried out in a recessed way in the niche designed for this purpose and that keeps the connection points of the PAR56 submersible LED bulb protected. In this way, its correct operation is guaranteed.

Not recommended test the product for more than 20 seconds out of the water.

This spotlight offers instant start-up, it has a degree of protection IP68 (valid for working under water) , in addition to being robust enough for the required mechanical requirements. Made of ABS and PC with a white finish.

*IMPORTANT: Not recommended for use in saltwater pools. Causes interference in light control.
