1 4

LED Track Light 40W, 90 lm/W, CCT (Adjustable Light Tone), 3-Phase Lifud Driver, 50,000 hours

LED Track Light 40W, 90 lm/W, CCT (Adjustable Light Tone), 3-Phase Lifud Driver, 50,000 hours

See questions and answers

  • + Lifud Driver
  • SKU:JW-TR40W-CCT
F
Reference Stock Price Discount Amount
CCT
SKU: JW-TR40W-CCT
Stock available soon
Available
35,41€
35,41€
For additional amounts the delivery period is 60 days As of the order date

Warranty

  • Warranty 5 years
  • Eye Care Eye Care
  • Tüv Süd TUV SUD
  • 36 º Opening
  • Certificado ENEC

Technical file

Product code
JW-TR40W-CCT
Light temperature
CCT
Power (W)
40.0
Luminosity (LM)
3600
Luminous efficacy (LM/W)
90
Type of LEDs
Bridgelux LED
Number of LEDs
1
LED efficacy
110
Opening Angle (º)
36
CRI
95
UGR
◄15
Power factor (PF)
0.99
Construction
Alu/PC
Facility
IP20
Strain
190-260VAC
Long
110.0
Measures (mm)
110x105x105
Broad
105.0
High
105.0
Isolation class
II
Estimated life (H)
50000
Work frequency (Hz)
50/60
Start time (s)
0.1
Energy class
E
Certificates
CE/ROHS/ISO9001
Temperature range (ºC)
-20+40
Lighting cycles
100000
Energy consumption (kWh/1000h)
40.0
Weight (gr)
3000
Flicker
0.88
Half -year useful life (at 3 h/day)
45.66
Half -Year Useful Life (5 h/day)
27.39
Half -year useful life (at 8 h/day)
17.12
Minimum cri range
90
Maximum cri range
99
Minimum CCT range
3000
Maximum cri range
6000
Driver
Lifud
Diameter
110

Characteristics

Product code
JW-TR40W-CCT
Light temperature
CCT
Power (W)
40.0
Luminosity (LM)
3600
Luminous efficacy (LM/W)
90
Type of LEDs
Bridgelux LED
Number of LEDs
1
LED efficacy
110
Opening Angle (º)
36
CRI
95
UGR
◄15
Power factor (PF)
0.99
Construction
Alu/PC
Facility
IP20
Strain
190-260VAC
Long
110.0
Measures (mm)
110x105x105
Broad
105.0
High
105.0
Isolation class
II
Estimated life (H)
50000
Work frequency (Hz)
50/60
Start time (s)
0.1
Energy class
E
Certificates
CE/ROHS/ISO9001
Temperature range (ºC)
-20+40
Lighting cycles
100000
Energy consumption (kWh/1000h)
40.0
Weight (gr)
3000
Flicker
0.88
Half -year useful life (at 3 h/day)
45.66
Half -Year Useful Life (5 h/day)
27.39
Half -year useful life (at 8 h/day)
17.12
Minimum cri range
90
Maximum cri range
99
Minimum CCT range
3000
Maximum cri range
6000
Driver
Lifud
Diameter
110

Description

The CRI95 CCT Three-Phase LED Track Light offers solutions for all types of retail. It provides versatile lighting, perfect for ever-changing spaces where decorative elements or displayed products need to be highlighted. It boasts high efficacy (90 Lm/m), consuming 40 W using one high-power COB LED, and has a color rendering index of 95. Its consumption represents 40 kWh/1000 h, reducing the amount of energy billed and polluting gas emissions into the atmosphere. The spotlight has a base designed to support its total weight, has an IP20 protection rating (valid for indoor dust and humidity), and is robust enough to withstand the required mechanical demands. It is made of quality materials such as aluminum and incorporates high-performance components. It has a long lifespan of 50,000 hours, ten times longer than that of a conventional spotlight. Its installation on a three-phase track is very simple and allows the luminaire to be moved along the track. This provides a highly flexible lighting system that adapts to any situation. Its use is primarily found in the tertiary sector in spaces such as shops, exhibition halls, shopping malls, hotels, etc. Places that require versatile accent lighting that adapts to the layout of the products on display.

Documents

Installation_manual
Eu_certificates
Technical_drawings
