LED Floodlight 200W 24,000Lm 6000ºK IP65 50,000H [HO-FH-200W-CW]

LED Floodlight 200W 24,000Lm 6000ºK IP65 50,000H [HO-FH-200W-CW]

See questions and answers

  • Brand:GreenIce + Epistar Led
  • SKU:HO-HP-200W-CW
Eprel file
Reference Stock Price Discount Amount
6000K: Cool White
SKU: HO-HP-200W-CW
Free delivery in 48 h ... if you ask before
Stock available
50,17€
50,17€
4200K: Daylight
SKU: HO-HP-200W-W
Free delivery in 48 h ... if you ask before
Stock available
50,17€
50,17€
3000K: Warm White
SKU: HO-HP-200W-WW
Free delivery in 48 h ... if you ask before
Stock available
50,17€
50,17€
For additional amounts the delivery period is 60 days As of the order date

Warranty

  • Warranty 3 years
  • Eye Care Eye Care
  • 120 º Opening

Technical file

Product code
HO-HP-200W-CW
Light temperature
Cold White
Power (W)
200.0
Luminosity (LM)
24000
Luminous efficacy (LM/W)
120
Type of LEDs
Epistar Led
LED efficacy
132
Opening Angle (º)
120
CRI
80
Power factor (PF)
0.99
Construction
Aluminum/Glass
Facility
IP65
Strain
100-240VAC
Driver output
DC24V -80V 1200MA
Long
310.0
Measures (mm)
310x345x95
Broad
85.0
High
345.0
Isolation class
I
Estimated life (H)
50000
Dimable
No
Equivalence (W)
1070
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
E
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20 +65
Lighting cycles
100000
Diffuser
Transparent
Kelvin º
6000
Energy consumption (kWh/1000h)
200.0
Weight (gr)
5150
Flicker
0.6
Half -year useful life (at 3 h/day)
45.66
Half -Year Useful Life (5 h/day)
27.39
Half -year useful life (at 8 h/day)
17.12
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
2
Minimum cri range
98
Maximum cri range
1
Chromaticity x
0.304
Chromaticity and
0.312
IK Protection Index
IK08
Número unidades caja exterior
5.0
Applicable standards
EN 55015:2013; EN 61000-3-2:2014; EN 61000-3-3:2013; EN 61547:2009; EN 60598-1:2015; EN 60598-2-5:2015; EN 62031:2008:2015; EN 62471:2008; EN 62493:2015; IEC 62321:2008; IEC 62321:2013; IEC 62321:2015

Characteristics

Product code
HO-HP-200W-CW
Light temperature
Cold White
Power (W)
200.0
Luminosity (LM)
24000
Luminous efficacy (LM/W)
120
Type of LEDs
Epistar Led
LED efficacy
132
Opening Angle (º)
120
CRI
80
Power factor (PF)
0.99
Construction
Aluminum/Glass
Facility
IP65
Strain
100-240VAC
Driver output
DC24V -80V 1200MA
Long
310.0
Measures (mm)
310x345x95
Broad
85.0
High
345.0
Isolation class
I
Estimated life (H)
50000
Dimable
No
Equivalence (W)
1070
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
E
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20 +65
Lighting cycles
100000
Diffuser
Transparent
Kelvin º
6000
Energy consumption (kWh/1000h)
200.0
Weight (gr)
5150
Flicker
0.6
Half -year useful life (at 3 h/day)
45.66
Half -Year Useful Life (5 h/day)
27.39
Half -year useful life (at 8 h/day)
17.12
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
2
Minimum cri range
98
Maximum cri range
1
Chromaticity x
0.304
Chromaticity and
0.312
IK Protection Index
IK08
Número unidades caja exterior
5.0
Applicable standards
EN 55015:2013; EN 61000-3-2:2014; EN 61000-3-3:2013; EN 61547:2009; EN 60598-1:2015; EN 60598-2-5:2015; EN 62031:2008:2015; EN 62471:2008; EN 62493:2015; IEC 62321:2008; IEC 62321:2013; IEC 62321:2015

Description

The SMD5730 Outdoor LED Projector Spotlight in black color stands out for its compact and slim design.

It has 200W of power, 100-240VAC power supply, a power factor of 0.99 and SMD optics. Its IP65 degree of protection makes it ideal for outdoors. Its color rendering index (CRI) is Ra&gt80 and it has an estimated useful life of 50,000 hours.

It mounts a special transparent diffuser that significantly reduces the inconvenience caused by glare, achieving a UGR&lt index

Documents

Installation_manual
Spanish_technical_data
Eu_certificates
Technical_drawings
