LED Floodlight IP65 150W 13550Lm 100,000H

LED Floodlight IP65 150W 13550Lm 100,000H

See questions and answers

  • Brand:GreenIce
  • SKU:SG-FL-150-AW-CW
Eprel file
Reference Stock Price Discount Amount
6000K: Cool White
SKU: SG-FL-150-AW-CW
Free delivery in 48 h ... if you ask before
There are few
67,18€
67,18€
For additional amounts the delivery period is 30 days As of the order date

Warranty

  • Warranty 3 years
  • Tüv Süd TUV SUD
  • 120 º Opening
  • Certificado ENEC

Technical file

Product code
SG-FL-150-AW-CW
Light temperature
Cold White
Power (W)
150.0
Luminosity (LM)
13550
Luminous efficacy (LM/W)
90
Type of LEDs
COB Bridgelux
LED efficacy
99
Opening Angle (º)
120
CRI
85
Power factor (PF)
0.9
Construction
Aluminum/Glass
Facility
IP65
Strain
100-240VAC
Measures (mm)
360x279
Broad
360.0
High
279.0
Isolation class
I
Estimated life (H)
100000
Dimable
No
Equivalence (W)
600
Work frequency (Hz)
50/ 60
Start time (s)
0.2
Energy class
F
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20 +65
Lighting cycles
100000
Diffuser
Transparent
Kelvin º
6000
Energy consumption (kWh/1000h)
150.0
Weight (gr)
10300
Flicker
0.95
Half -year useful life (at 3 h/day)
91.32
Half -Year Useful Life (5 h/day)
54.79
Half -year useful life (at 8 h/day)
34.24
Single/range CCT
Only
Single CCT
6000
INDEX R9
24
Minimum cri range
95
Maximum cri range
1
Chromaticity x
0.323
Chromaticity and
0.352
IK Protection Index
IK08

Characteristics

Product code
SG-FL-150-AW-CW
Light temperature
Cold White
Power (W)
150.0
Luminosity (LM)
13550
Luminous efficacy (LM/W)
90
Type of LEDs
COB Bridgelux
LED efficacy
99
Opening Angle (º)
120
CRI
85
Power factor (PF)
0.9
Construction
Aluminum/Glass
Facility
IP65
Strain
100-240VAC
Measures (mm)
360x279
Broad
360.0
High
279.0
Isolation class
I
Estimated life (H)
100000
Dimable
No
Equivalence (W)
600
Work frequency (Hz)
50/ 60
Start time (s)
0.2
Energy class
F
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20 +65
Lighting cycles
100000
Diffuser
Transparent
Kelvin º
6000
Energy consumption (kWh/1000h)
150.0
Weight (gr)
10300
Flicker
0.95
Half -year useful life (at 3 h/day)
91.32
Half -Year Useful Life (5 h/day)
54.79
Half -year useful life (at 8 h/day)
34.24
Single/range CCT
Only
Single CCT
6000
INDEX R9
24
Minimum cri range
95
Maximum cri range
1
Chromaticity x
0.323
Chromaticity and
0.352
IK Protection Index
IK08

Description

The 360x279mm LED spotlight, with a thickness of 130mm, offers solutions for outdoor and indoor environments for both industrial and residential use. It can be installed directly to outlets supplied by the electrical network (100-240VAC) with a service frequency of 50/60Hz.

It has a high efficiency (90 Lm/W) consuming 150W through two BRIDGELUX COB type LEDs, managing to provide a luminous flux of 13550Lm uniformly distributed through a transparent diffuser from which a color rendering index of 90 is obtained. It provides lighting equivalent to a 600W incandescent bulb, its consumption represents a value of 150kWh/1000h, reducing the amount of energy billed and the emissions of polluting gases into the atmosphere. The projector has an IP65 degree of protection (valid for dust and humidity outdoors), in addition to being robust enough for the required mechanical demands.
