LED Track Spotlight 15W 1200Lm CRI85 4200ºK Lumiastra Single Phase 40,000H [LUM-ATH070015-BW]

LED Track Spotlight 15W 1200Lm CRI85 4200ºK Lumiastra Single Phase 40,000H [LUM-ATH070015-BW]

See questions and answers

  • Brand:GreenIce + Lumiastra
  • SKU:LUM-ATH070015-B-W
Eprel file
Reference Stock Price Discount Amount
6000K: Cool White
SKU: LUM-ATH070015-B-CW
Ask for it and collect it in 60 days
Exhausted
10,92€
10,92€
4200K: Daylight
SKU: LUM-ATH070015-B-W
Delivery in 48 h ... if you ask before
Stock available
10,92€
10,92€
2700K: Warm White
SKU: LUM-ATH070015-B-WW
Delivery in 48 h ... if you ask before
There are few
10,92€
10,92€
For additional amounts the delivery period is 60 days As of the order date

Warranty

  • Warranty 3 years
  • 38 º Opening
  • Certificado ENEC

Accessories

Technical file

Product code
LUM-ATH070015-B-W
Light temperature
Natural White
Power (W)
15.0
Luminosity (LM)
1200
Luminous efficacy (LM/W)
80
Type of LEDs
COB
Number of LEDs
1
LED efficacy
88
Opening Angle (º)
38
CRI
85
UGR
◄17
Power factor (PF)
0.9
Construction
Aluminum/ PC
Facility
IP20
Strain
220-240VAC
Measures (mm)
Ø77x256
High
256.0
Isolation class
II
Estimated life (H)
40000
Dimable
No
Equivalence (W)
100
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
G
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20 +40
Lighting cycles
100000
Diffuser
Transparent
Kelvin º
4200
Energy consumption (kWh/1000h)
15.0
Weight (gr)
200
Flicker
0.91
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Directional
Single/range CCT
Only
Single CCT
4200
INDEX R9
3
Minimum cri range
95
Maximum cri range
3
Chromaticity x
0.377
Chromaticity and
0.374
Diameter
77
Applicable standards
EN 55015:2006; EN 61547:2009; EN 61000-3-2:2006; EN61000-3-3:2008; EN 60598-2-1:1989; EN 60598-1:2008; EN 61347-1:2008; EN 61347-2-13:2006; EN 62031:2008; EN 62471:2008; EN 62493:2010

Characteristics

Product code
LUM-ATH070015-B-W
Light temperature
Natural White
Power (W)
15.0
Luminosity (LM)
1200
Luminous efficacy (LM/W)
80
Type of LEDs
COB
Number of LEDs
1
LED efficacy
88
Opening Angle (º)
38
CRI
85
UGR
◄17
Power factor (PF)
0.9
Construction
Aluminum/ PC
Facility
IP20
Strain
220-240VAC
Measures (mm)
Ø77x256
High
256.0
Isolation class
II
Estimated life (H)
40000
Dimable
No
Equivalence (W)
100
Work frequency (Hz)
50/ 60
Start time (s)
0.1
Energy class
G
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20 +40
Lighting cycles
100000
Diffuser
Transparent
Kelvin º
4200
Energy consumption (kWh/1000h)
15.0
Weight (gr)
200
Flicker
0.91
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Directional
Single/range CCT
Only
Single CCT
4200
INDEX R9
3
Minimum cri range
95
Maximum cri range
3
Chromaticity x
0.377
Chromaticity and
0.374
Diameter
77
Applicable standards
EN 55015:2006; EN 61547:2009; EN 61000-3-2:2006; EN61000-3-3:2008; EN 60598-2-1:1989; EN 60598-1:2008; EN 61347-1:2008; EN 61347-2-13:2006; EN 62031:2008; EN 62471:2008; EN 62493:2010

Description

The single-phase Lumiastra LED track light with a black finish offers solutions for all types of businesses.It provides versatile lighting that is perfect for ever-changing spaces, where it is necessary to highlight decorative elements or products exposed.

It has a high efficiency (80Lm/m), consuming 15W through 1 high power COB LED, managing to provide a luminous flux of 1200Lm passing through a transparent diffuser, it has a color rendering index of 85. Its consumption represents a value of 15kWh/1000h, reducing the amount of energy billed and the emissions of polluting gases into the atmosphere.

The spotlight has a base designed to support its total weight, It has an IP25 degree of protection (valid for dust and humidity indoors), in addition to being robust enough for the required mechanical demands.

It is made of quality materials such as aluminum and incorporates high performance components. It has a long useful life of 30,000 hours, ten times longer than that of a conventional spotlight.

Its installation on the single-phase track is very simple and allows the movement of the luminaire on the rail. This allows for a very flexible lighting system that adapts to any situation.

Its use is mainly in the tertiary sector in spaces such as shops, exhibition halls, galleries shops, hotels, etc. Places that require a versatile accent light that adapts to the layout of the products on display.

This spotlight emits a natural white color tone (4200 °K) and in warm white (3000°K). The indicated color temperature may suffer fluctuations corresponding to a tolerance of 7%.
