Linkable LED Tube IP65 36W 4000Lm 6510ºK 120Cm 40,000H [HO-FSG-001-1.2M-CW]

Linkable LED Tube IP65 36W 4000Lm 6510ºK 120Cm 40,000H [HO-FSG-001-1.2M-CW]

See questions and answers

  • Brand:GreenIce
  • SKU:HO-FSG-001-1.2M-CW
Eprel file
Reference Stock Price Discount Amount
6000K: Cool White
SKU: HO-FSG-001-1.2M-CW
Delivery in 48 h ... if you ask before
Stock available
9,06€
9,06€
4000K: Daylight
SKU: HO-FSG-001-1.2M-W
Delivery in 48 h ... if you ask before
Stock available
9,06€
9,06€
For additional amounts the delivery period is 60 days As of the order date

Warranty

  • Warranty 3 years
  • Eye Care Eye Care
  • 120 º Opening

Technical file

Product code
HO-FSG-001-1.2M-CW
Light temperature
Cold White
Power (W)
36.0
Luminosity (LM)
4000
Luminous efficacy (LM/W)
111
Type of LEDs
SMD2835
Number of LEDs
96
LED efficacy
122
Opening Angle (º)
120
CRI
80
Power factor (PF)
0.9
Construction
PC
Facility
IP65
Strain
220VAC
Long
1200.0
Measures (mm)
56x30x1200
Broad
56.0
High
30.0
Isolation class
II
Estimated life (H)
40000
Dimable
No
Work frequency (Hz)
50/60
Start time (s)
0.1
Energy class
E
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20+60
Lighting cycles
100000
Diffuser
Opal
Kelvin º
6000
Energy consumption (kWh/1000h)
36.0
Weight (gr)
345
Flicker
0.95
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
-25
Minimum cri range
79
Maximum cri range
1
Chromaticity x
0.311
Chromaticity and
0.33
IK Protection Index
IK07
Número unidades caja exterior
20.0
Applicable standards
EN 55015:2006; EN 61547:2009; EN 61000:2008; EN 60598:2008; EN 62471:2008

Characteristics

Product code
HO-FSG-001-1.2M-CW
Light temperature
Cold White
Power (W)
36.0
Luminosity (LM)
4000
Luminous efficacy (LM/W)
111
Type of LEDs
SMD2835
Number of LEDs
96
LED efficacy
122
Opening Angle (º)
120
CRI
80
Power factor (PF)
0.9
Construction
PC
Facility
IP65
Strain
220VAC
Long
1200.0
Measures (mm)
56x30x1200
Broad
56.0
High
30.0
Isolation class
II
Estimated life (H)
40000
Dimable
No
Work frequency (Hz)
50/60
Start time (s)
0.1
Energy class
E
Certificates
CE/ROHS/ISO9001
Bush
Terminal Block
Temperature range (ºC)
-20+60
Lighting cycles
100000
Diffuser
Opal
Kelvin º
6000
Energy consumption (kWh/1000h)
36.0
Weight (gr)
345
Flicker
0.95
Half -year useful life (at 3 h/day)
36.52
Half -Year Useful Life (5 h/day)
21.91
Half -year useful life (at 8 h/day)
13.69
Directional
Non-Directional
Single/range CCT
Only
Single CCT
6000
INDEX R9
-25
Minimum cri range
79
Maximum cri range
1
Chromaticity x
0.311
Chromaticity and
0.33
IK Protection Index
IK07
Número unidades caja exterior
20.0
Applicable standards
EN 55015:2006; EN 61547:2009; EN 61000:2008; EN 60598:2008; EN 62471:2008

Description

The LED Waterproof Unit offers energy savings of more than 50% compared to a conventional waterproof unit.

Incredible lighting results and sealing, thanks to its materials resistant to water, dust and corrosion, with an IP65 protection factor. It is ideal for replacing conventional screens with fluorescent tubes.

It has an innovative design with an opal diffuser. Ideal for areas that require many hours of lighting such as car parks, car parks, warehouses, offices, schools, etc.

The main advantages are:

  • It does not require maintenance. Durability, more than 30,000 hours thanks to its components of the highest quality.
  • Simple installation, connects directly to the network.
  • Instant start-up and does not affect your hours of life.
  • Resistance against shocks and vibrations. It does not emit noise.
  • They do not need any gas to ignite.
  • High Color Rendering Index &gt 80.
  • IK08.
"
